Type of detector - Wireless
Installation method - Indoors
Compatibility
Operates with all Ajax hubs, range extenders, ocBridge Plus, uartBridge
Sensing element - PIR sensor, electret microphone
Alarm signal delivery time - 0.15 s
Motion detection distance - Up to 12 m
Detection angles
Horizontal — 88.5°
Vertical — 80°
Time for motion detection - From 0.3 to 2 m/s
Recommended installation height - 2.4 m
Pet immunity
Weight — up to 20 kg
Height — up to 50 cm
Break detection distance - Up to 9 m
Detection angle -180°
Sensitivity - Adjustable, 3 levels
Power supply
Battery: CR123A battery, 3 V
Battery life
Up to 5 years
Jeweller radio technology
Communication range with central unit — up to 1,200 m in an open space
Two-way communication between devices
Operating frequencies — 868.0-868.6 MHz
Self-adjusting RF output power — up to 20 mW
Block encryption based on AES algorithm
Detector polling period — 12−300 s
Temperature sensor - Available
Operating temperature range - From -10°С to +40°С
Permissible humidity - Up to 75%
Anti-sabotage
Protection against fraud
Jamming detection
Tamper-resistant
Remote setting and testing - Available
Dimensions - 110 × 65 × 50 mm
Weight - 92 g
