Classification - Surface sound radio channel security detector
Type of detector - Wireless
Installation method - Indoors
Compatibility - Operates with all Ajax hubs, range extenders, ocBridge Plus, uartBridge
Sensing element - Electret microphone
Break detection distance - Up to 9 m
Alarm signal delivery time - 0.15 s
Sensitivity - Adjustable, 3 levels
Detection angle - 180°
Power supply
Battery: CR123A battery, 3 V
Battery life
Up to 7 years
Jeweller radio technology
Communication range with central unit — up to 1,000 m in an open space
Two-way communication between devices
Operating frequencies — 868.0 - 868.6 MHz
Self-adjusting RF output power — up to 20 mW
Block encryption based on AES algorithm
Detector polling period — 12−300 s
Temperature sensor - Available
Operating temperature range - From -10°С to +40°С
Permissible humidity - Up to 75%
Anti-sabotage
Protection against fraud
Jamming detection
Tamper-resistant
Remote setting and testing - +
Dimensions - Diameter: 20 mm
Height - 90 mm
Weight - 30 g
